STYLE MEETS PIVOT DOORS
Each development has its own character and we deliver fully customizable doors solutions that realize your architectural vision.
Whether your project favors modern minimalism, transitional luxury, or classical timelessness, we work closely with your design and construction teams to create entrances that enhance the space. From large pivot entries, every product is made-to-order and precisely tailored to the project’s layout, function, and aesthetic language.
From large pivot entries, every product is made-to-order and precisely tailored to the project’s layout, function, and aesthetic language.
- Multi-point locking
- Certified Materials
- Teak Wood and Oak Wood
- Pivot doors are 3 1/4′′ thick
Our Products
Gallery
Spaces We've Designed
Traditional
Crafted from premium materials and customizable finishes, they accommodate large-format glazing or solid wood faces, integrate high-performance hardware and weatherproofing, and deliver refined operation, enhanced security, and modern architectural impact.
- Structural core: internal metal frame
- Security features
- Thermal & acoustic isolation
Contemporary
Contemporary pivot doors merge minimalist form with bold presence: oversized panels appear to float on a precision pivot, creating dramatic, uninterrupted sightlines and a seamless transition between interior and exterior.
- Security & hardware integration
- Smooth operation
- Oversized capability
Modern
Imagine a door that seems to float in its frame. Our pivot doors transform every arrival into an architectural moment—clean, bold, and unmistakably modern.
- Customizable finishes
- Impact-rated options
- Weatherproofing & durability
Size and Space Compatibility for Pivot Doors
Size and Space Compatibility for Pivot Doors
When selecting and installing a pivot door, precise measurements and space planning are crucial to ensure both functionality and aesthetics. Verify the rough opening, swing path, clearance, and allowances for finishes and hardware before ordering.
Door panel size and proportion
Width
Pivot doors are typically wider than standard doors. Common widths range from 42 in to 72 inch. The ideal width should balance passage needs with the room’s visual harmony.
Height
A standard door height is about 120 – 140 inch, but pivot doors are often taller for greater visual impact. Note that increased height raises weight, requiring a heavier‐duty pivot system.
Swing Radius and Clearance
Swing radius
Pivot doors rotate around an axis and require clear distance to open. The swing radius depends on the pivot point and the door width. Off‐center (offset) pivot designs typically need less space, while center‐pivot doors require more.
Clearance
Ensure the swing path is free of obstacles. Allow at least the door panel’s width as clear space to ensure unhindered movement.
Door opening dimensions and installation requirements
Rough opening width: The rough opening should be slightly wider than the door panel to accommodate pivot hardware and allow proper operation. Typical allowance: add about 1/2″ to 1″ (12–25 mm) to the panel width for the jamb and pivot clearances.
Rough opening height: Allow extra clearance above the door panel for the top pivot assembly and any finishing clearances. Typical allowance: add about 1/2″ to 1″ (12–25 mm) to the panel height; taller/custom doors may require additional clearance per manufacturer specs.
Floor and ceiling load capacity
A pivot door’s weight is typically supported by both the floor and the top pivot at the header. For large or heavy panels, evaluate the structural load capacity of the floor and ceiling/header in advance to prevent long‐term issues such as sagging or misalignment.
Professional measurement and customization
Due to the technical nature of pivot doors, hiring a professional for on‐site measurement and custom design is strongly recommended. A qualified team will tailor the solution to your space, ensuring both proper function and seamless aesthetic integration.
Pivot door styles and design compatibility
Pivot doors are defined by their unique vertical rotation, making them a striking architectural feature. Choosing a pivot door style that complements your interior or exterior design is essential. Below are popular residential styles and recommended pivot door design pairings.
Testimonials
GET STARTED
Start Your Project Today
Minimalist and Scandinavian styles or traditional and classic styles…are the best fits for pivot doors!
